Description:
Apple iphone 5 s / 5 after dismantling LCD special tool fixture chuck teardown platform
Received the new screen removal jig, please make sure that can successfully remove the iPhone from the jig
Adjustment process:
Remove all sheath or screen protective film.
Insert a do not belong to the customer the iPhone 5 screen removal jig
Loosen the hexagon screws, you can adjust the size of the screen left and right.
Flip down the red locking lever to secure the device.
Flips the red locking lever to release the device
Operational procedures:
1, iphoen5s or 5C tail screws removed.
2, put the phone on the platform, the screen facing up.
3, push the red locking lever, the phone fixed on the table.
4, the suction cup lever depressed, so that sucker adsorbed on the phone screen glass.
5, take a hand against the screen, one hand held up lever, separate screens.
6, when the phone screen and separated from the suction side to pull the look, from the sucker.
7, take the time to pay attention to the phone, there is cable connection between the screen and the phone motherboard.
Item:
1* LCD Screen Removal Touch Glass Separator Special Tools For iPhone 4 4S iPhone 5/5C/5S
